Tyres

Tyre Width175

Tyre Profile65

Tyre Speed RatingH

TypeConventional/summer

Official Brochure Tyre SizeYes

Diameter15

Paint

TypeGloss

Door mirrors/cameras

TypeElectrically Adjustable

HeatedYes

ColourPainted

Indicator LightsYes

Rear windscreen

TypeFixed

WipersIntermittent

Wheels

Rim TypeAlloy

Rim Diameter (in)15

Rim Width (in)5

Spare wheel

TypeSpace Saver

Rim TypeSteel

External dimensions

Overall Length (mm)3950

Overall Width (mm)1695

Overall Height (mm)1510

Ground Clearance Unladen (mm)135

Wheelbase (mm)2510

Front Track (mm)1470

Rear Track (mm)1460

Kerb To Kerb Turning Circle (mm)9600

Overall Length (in)155.5

Overall Width (in)66.7

Overall Height (in)59.4

Ground Clearance Unladen (lbs)5.3

Wheelbase (in)98.8

Front Track (in)57.9

Rear Track (in)57.5

Kerb To Kerb Turning Circle (ft)31.5

Internal dimensions

Headroom Front (mm)998

Headroom Rear (mm)955

Hip Room Front (mm)1270

Hip Room Rear (mm)1273

Leg Room Front (mm)1031

Leg Room Rear (mm)846

Shoulder Room Front (mm)1334

Shoulder Room Rear (mm)1315

Headroom Front (in)39.3

Headroom Rear (in)37.6

Hip Room Front (in)50

Hip Room Rear (in)50.1

Leg Room Front (in)40.6

Leg Room Rear (in)33.3

Shoulder Room Front (in)52.5

Shoulder Room Rear (in)51.8

Load compartment capacity

Rear Seat Up To Lower Window (l)286

Rear Seat Down To Roof (l)768

Measurement StandardVDA

Rear Seat Up To Lower Window (cu Ft)10.1

Rear Seat Down To Roof (cu Ft)27.1

Fuel tanks

TypeMain

Capacity (l)42

Capacity (gal)11.1

Capacity (UK Gallons)9.2

Weights

Gross Vehicle Weight (kg)1545

Published Kerb Weight (kg)1115

Gross Trailer Weight Braked (kg)835

Gross Trailer Weight Unbraked (kg)550

Kerb Weight Includes DriverYes

Measurement StandardEU

Gross Vehicle Weight (lbs)3406

Published Kerb Weight (lbs)2458

Gross Trailer Weight Braked (lbs)1841

Gross Trailer Weight Unbraked (lbs)1213

Disc brakes

Number Of2

Number Of Ventilated Discs2

Parking distance sensors

TypeCamera

Parking distance system

TypeCamera

Headlights

Lens TypeEllipsoidal

Bulb Type (low Beam)Halogen

Bulb Type (high Beam)Halogen

Headlight control

Auto HighbeamYes

Height AdjustmentManual

Front airbag

Occupant Switch OffYes

Head restraints

Height AdjustableYes

Number3

Front seat belts

Seat PositionPassenger

Pre-tensionersYes

Rear seat belts

Seat PositionCentre

Type3-point

Low tyre pressure indicator

Rim Mounted SensorYes

Anti collision system

Activates Brake LightsYes

Automatic BrakingYes

Automatic Emergency BrakingYes

Minimum Speed To Activate (kph)10

Visual/acoustic WarningYes

Cruise control

Adaptive Cruise ControlYes

Adaptive Cruise Control (ACC)Yes

Engine

Cc1496

Litres1.5

Bore72.5

Stroke90.6

Compression Ratio13.5

Number Of Cylinders4

ConfigurationIn-line

Variable Valve Timing/camshaftYes

Number Of Valves Per Cylinder4

Engine Code2NR-KFE

Emission control level

Standard MetEU6

CO2 Level - G/km Combined109

CO (g/km)0.3736

HC (g/km)0.043

NOx Level (g/km)0.015

Noise Level (dB)69

Fuel system

Injection/carburationMulti-point Injection

Fuel

Fuel TypeUnleaded

Fuel Type Octane No.95

Generic Primary Fuel TypePetrol

Performance

Maximum Speed (km/h)175

Acceleration 0-62mph (s)11

Maximum Speed (mph)109

Power

Measurement StandardEEC

Maximum Power KW82

Maximum Power Hp/PS111

Rpm For Maximum Power (low)6000

Maximum Torque Nm136

Rpm For Maximum Torque (low)4400

Primary Or Secondary Fuel Power FigurePrimary

Power steering

Vehicle Speed ProportionalYes

TypeElectric

Suspension

TypeTorsion Beam

Anti-roll BarYes

Wheel DependenceSemi-independent

Spring TypeCoil

Traffic light coding

Efficiency LabelF

Main service

Distance (km)16093

Period (mths)12

Distance (miles)10000

Fuel consumption

StandardECE 99/100

Urban (l/100km)6.2

Country/highway (l/100km)4

Combined (l/100km)4.8

Urban (km/l)16.1

Country/highway (km/l)25

Combined (km/l)20.8

Combined Vehicle Range (km)875

Calculated Vehicle Range (km)875

Combined Vehicle Range (miles)544

Calculated Vehicle Range (miles)544

Urban (mpg)38

Country/highway (mpg)59

Combined (mpg)49

Urban (miles Per UK Gallon)46

Country/highway (miles Per UK Gallon)71

Combined (miles Per UK Gallon)59

Powertrain type

TypeCombustion

Powertrain

TypeCombustion
