Aerial

TypeRoof

Coefficient of drag

Coefficient Of Drag0.37

Bumpers

ColourPainted

Tyres

Tyre Width165

Tyre Profile60

Tyre Speed RatingT

TypeConventional/summer

Extra Load?

Paint

TypeMetallic

Door mirrors/cameras

TypeElectrically Adjustable

ColourBlack

Rear windscreen

TypeFixed

WipersConstant

Windscreen wipers

Intermittent WipeFixed

Wheels

Rim TypeAlloy

Rim Diameter (in)14

Rim Width (in)4.5

Spare wheel

TypeFull Size

Rim TypeSteel

Non-corrosive body

TypeGalvanised

External dimensions

Overall Length (mm)3500

Overall Width (mm)1620

Overall Height (mm)1700

Wheelbase (mm)2360

Front Track (mm)1420

Rear Track (mm)1385

Kerb To Kerb Turning Circle (mm)9800

Wall To Wall Turning Circle (mm)10600

Overall Length (in)137.8

Overall Width (in)63.8

Overall Height (in)66.9

Wheelbase (in)92.9

Front Track (in)55.9

Rear Track (in)54.5

Kerb To Kerb Turning Circle (ft)32.2

Wall To Wall Turning Circle (ft)34.8

Internal dimensions

Headroom Rear (mm)1045

Shoulder Room Front (mm)1345

Shoulder Room Rear (mm)1220

Headroom Rear (in)41.1

Shoulder Room Front (in)53

Shoulder Room Rear (in)48

Load compartment capacity

Rear Seat Up To Lower Window (l)300

Rear Seat Down To Roof (l)1250

Rear Seat Up To Lower Window (cu Ft)10.6

Rear Seat Down To Roof (cu Ft)44.1

Fuel tanks

TypeMain

Capacity (l)41

Fuel TypeUnleaded

Capacity (gal)10.8

Weights

Gross Vehicle Weight (kg)1355

Published Kerb Weight (kg)955

Gross Trailer Weight Braked (kg)650

Gross Trailer Weight Unbraked (kg)350

Gross Vehicle Weight (lbs)2987

Published Kerb Weight (lbs)2105

Gross Trailer Weight Braked (lbs)1433

Gross Trailer Weight Unbraked (lbs)772

Disc brakes

Number Of2

Headlights

Lens TypeConventional

Bulb Type (low Beam)Halogen

ConfigurationSingle

Headlight control

Internal Height AdjustmentYes

Head restraints

Height AdjustableYes

Number3

Front seat belts

Seat PositionPassenger

Type3-point

OperationReel

Pre-tensionersYes

Height AdjustableYes

Rear seat belts

Seat PositionCentre

Type3-point

OperationReel

Audio anti-theft protection

TypeDetachable Panel

Engine

Cc1298

Litres1.3

Bore74

Stroke75.5

Compression Ratio9.5

Number Of Cylinders4

ConfigurationIn-line

OrientationTransverse

Valve Gear TypeOverhead Cam

Number Of Valves Per Cylinder4

Engine CodeG13BB

Emission control level

Standard MetEU4

CO2 Level - G/km Combined152

Catalytic converter

Type3-way

Fuel system

Injection/carburationMulti-point Injection

Fuel

Fuel TypeUnleaded

Fuel Type Octane No.95

Generic Primary Fuel TypePetrol

Performance

Maximum Speed (km/h)155

Acceleration 0-62mph (s)12.8

Maximum Speed (mph)96

Power

Measurement StandardEEC

Maximum Power KW56

Maximum Power Hp/PS75

Rpm For Maximum Power (low)5500

Maximum Torque Nm115

Rpm For Maximum Torque (low)4250

Fuel consumption

StandardEU 96

Urban (l/100km)8.4

Country/highway (l/100km)5.3

Combined (l/100km)6.4

Urban (mpg)28

Country/highway (mpg)44

Combined (mpg)37

Power steering

Vehicle Speed ProportionalYes

TypeElectric

Suspension

TypeBeam

Anti-roll BarYes

Wheel DependenceRigid

Spring TypeCoil

Main service

Distance (km)14484

Period (mths)12

Distance (miles)9000

Insurance

Description3E-N2
