Aerial

TypeDiversity

Bumpers

ColourPainted

Tyres

Tyre Width255

Tyre Profile35

Tyre Speed RatingY

TypeConventional

Official Brochure Tyre SizeYes

Diameter20

Paint

TypeGloss

Door mirrors/cameras

TypeElectrically Adjustable

HeatedYes

ColourPainted

Indicator LightsYes

Rear windscreen

TypeFixed

Windscreen wipers

Rain SensorYes

Wheels

Rim TypeAlloy

Rim Diameter (in)20

Rim Width (in)8.5

Two-toneYes

Spare wheel

TypeSpace Saver

Rim TypeSteel

Non-corrosive body

TypeGalvanised

External dimensions

Overall Length (mm)4915

Overall Width (mm)1874

Overall Height (mm)1455

Wheelbase (mm)2912

Front Track (mm)1627

Rear Track (mm)1618

Wall To Wall Turning Circle (mm)11900

Overall Length (in)193.5

Overall Width (in)73.8

Overall Height (in)57.3

Wheelbase (in)114.6

Front Track (in)64.1

Rear Track (in)63.7

Wall To Wall Turning Circle (ft)39

Internal dimensions

Headroom Front (mm)1046

Headroom Rear (mm)962

Hip Room Front (mm)1527

Hip Room Rear (mm)1491

Shoulder Room Front (mm)1460

Shoulder Room Rear (mm)1429

Headroom Front (in)41.2

Headroom Rear (in)37.9

Hip Room Front (in)60.1

Hip Room Rear (in)58.7

Shoulder Room Front (in)57.5

Shoulder Room Rear (in)56.3

Load compartment capacity

Rear Seat Up To Lower Window (l)530

Measurement StandardVDA

Rear Seat Up To Lower Window (cu Ft)18.7

Fuel tanks

TypeMain

Capacity (l)73

Capacity (gal)19.3

Capacity (UK Gallons)16.1

Weights

Gross Vehicle Weight (kg)2205

Published Kerb Weight (kg)1625

Gross Trailer Weight Braked (kg)2000

Gross Trailer Weight Unbraked (kg)750

Measurement StandardEU

Gross Vehicle Weight (lbs)4861

Published Kerb Weight (lbs)3583

Gross Trailer Weight Braked (lbs)4409

Gross Trailer Weight Unbraked (lbs)1653

Disc brakes

Number Of4

Number Of Ventilated Discs2

Parking distance sensors

TypeSensor

Parking distance system

TypeSensor

Headlights

Lens TypeEllipsoidal

Bulb Type (low Beam)Bi-Xenon

Headlight control

Dusk SensorYes

Height AdjustmentAutomatic

Fog Light FunctionYes

Front airbag

Occupant Switch OffYes

IntelligentYes

Head restraints

Height AdjustableYes

Number3

Front seat belts

Seat PositionPassenger

Pre-tensionersYes

Height AdjustableYes

Rear seat belts

Seat PositionCentre

Type3-point

Anti-theft protection

Interior MonitoringYes

Engine

Cc1968

Litres2

Bore81

Stroke95.5

Compression Ratio15

Number Of Cylinders4

ConfigurationIn-line

Valve Gear TypeDouble Overhead Cam

Number Of Valves Per Cylinder4

Engine CodeCGLC

Compressor

CompressorTurbo

Emission control level

Standard MetEU6

CO2 Level - G/km Combined117

CO (g/km)0.224

Emission Particles (g/km)0

HC + NOx (g/km)0.107

NOx Level (g/km)0.066

Noise Level (dB)72

Fuel system

Injection/carburationDiesel Common Rail

Fuel

Fuel TypeDiesel

Generic Primary Fuel TypeDiesel

Performance

Maximum Speed (km/h)232

Acceleration 0-62mph (s)8.4

Maximum Speed (mph)144

Power

Measurement StandardEEC

Maximum Power KW140

Maximum Power Hp/PS190

Rpm For Maximum Power (low)3800

Maximum Torque Nm400

Rpm For Maximum Torque (low)1750

Primary Or Secondary Fuel Power FigurePrimary

Power steering

Vehicle Speed ProportionalYes

TypeElectric

Suspension

TypeMulti-link

Anti-roll BarYes

Wheel DependenceIndependent

Spring TypeCoil

Alternative suspension

TypeSport

Traffic light coding

Efficiency LabelC

Intermediate service

Distance (km)16093

Period (mths)12

Variable Distance/periodYes

Distance (miles)10000

Main service

Distance (km)32187

Period (mths)24

Variable Distance/periodYes

Distance (miles)20000

Fuel consumption

StandardECE 99/100

Urban (l/100km)5.2

Country/highway (l/100km)4

Combined (l/100km)4.5

Urban (km/l)19.2

Country/highway (km/l)25

Combined (km/l)22.2

Combined Vehicle Range (km)1622

Combined Vehicle Range (miles)1008

Urban (mpg)45

Country/highway (mpg)59

Combined (mpg)52

Urban (miles Per UK Gallon)54

Country/highway (miles Per UK Gallon)71

Combined (miles Per UK Gallon)63

Powertrain type

TypeCombustion

Insurance

Description28E-T1
